GRUNDFOS HYDRO MPCE-95055295-MPCE-CRE10-4-3X208-230

HYDRO MPC E 2CRE10-02 3X208V BASIS

Pressure booster system supplied as compact packaged assembly certified and listed by UL (Category QCZJ - Packaged Pumping Systems) for conformance to U.S. and Canadian Standards.

All pumps are speed-controlled. Each pump is equipped with an integrated variable frequency drive motor (MLE motor).

Hydro MPC-E maintains constant pressure through continuous adjustment of the speed of the pumps.
The system performance is adapted to the demand through cutting in/out the required number of pumps and through parallel control of the pumps in operation.
Pump changeover is automatic and depends on load, operating hours and fault.
All pumps in operation will run at equal speed.

The system consists of these parts:

2 vertical multistage centrifugal pumps, type CRE10-02.
Pump rotating parts in contact with the pumped liquid are made of ANSI 304 stainless steel as standard and ANSI 316 stainless steel as an option. Pump bases and pump heads are made of cast iron (Class 30) as standard and ANSI 316 stainless steel as an option. The pumps are equipped with the service-friendly cartridge type mechanical shaft seal HQQE (SiC/SiC/EPDM).
Suction manifold and discharge manifold made of 316 stainless steel.
Base frame made of 304 stainless steel.
One non-return valve (check valve), and two isolating valves for each pump.
Adapter with isolating valve for connection of diaphragm tank.
Pressure gauge and pressure transducer on each suction and discharge manifold. Dry-running protection is standard with use of pressure transducer on suction manifold.
Control MPC in a NEMA 4 steel control panel enclosure including main disconnect switch, all required fuses, motor protection, switching equipment and microprocessor-controlled CU 351.

Diaphragm tank is available as an accessory.


Product name	HYDRO MPC E 2CRE10-02 3X208V BASIS
Product No.	95055293
EAN	5700836978676

Technical
Actual calculated flow	110 US gpm
Max flow	136 US gpm
Max flow system	136 US gpm
Resulting head of the pump	70 ft
Head max	95.81 ft
Impellers main	2
Main pump name	CRE10-02
Main pump Number	96705084
Number of pumps	2
Non-ret. valve	at discharge side

Installation
Maximum operating pressure	232.06 psi
Maximum permissible inlet pressure	116.03 psi
Flange standard	NPT
Pump inlet	64
Pump outlet	64

Liquid
Pumped liquid	Water
Liquid temperature range	32 .. 140 °F
Selected liquid temperature	68 °F
Density	62.29 lb/ft³

Electrical data
Power (P2) main pump	1.5 HP
Main frequency	60 Hz
Rated voltage	3 x 3X208-230V, 60 Hz
Starting main	electronically
Rated current of system	11.7 A
Enclosure class (IEC 34-5)	UL Type 3R/12

Controls
Control type	E
Operation unit	CU 352

Tank
Diaphragm tank	No

Others
Net weight	472 lb
Language	EN
Product range	NAMREG
Configuration file Hydro MPC	95043547
Country of origin	US
Custom tariff no.	8413.70.2040
