We Have Your Building Covered-Grundfos-MPCE BoosterpaQ

Grundfos Hydro MPCE-We Have Your Building Covered copy
Download Brochure I&O Manual Specification



Hurley Pumps Service Pro

Pump Selection Program

NUMBER OF PUMPS PUMP MODEL HP HEADER SIZE 3 x 208-230 V 3 x 460 V Quick Pick Selection
P/N P/N Flow in GPM Head in Ft
MIN MID MAX MIN MID MAX
I-QS Hydro MPC E CRE 10
2 CRE 10-2 3 2.5" NPT 95055293 95055123 54 110 126 95 70 50
CRE 10-4 3 95055295 95055125 54 110 126 190 145 110
CRE 10-6 5 95055297 95055127 54 110 126 285 220 160
3 CRE 10-4 3 3" NPT 95055326 95055159 81 165 189 190 145 110
CRE 10-6 5 95055328 95055161 81 165 189 285 220 160
I-QS Hydro MPC E CRE 15
2 CRE 15-2 5 4'' ANSI 150# 95055301 95055131 90 180 240 130 105 70
CRE 15-3 7.5 95055302 95055132 90 180 240 180 150 100
CRE 154 7.5 95055303 95055133 90 180 240 250 210 140
CRE 15-5 10   95058724 90 180 240 315 255 175
3 CRE 15-2 5 4" ANSI 150# 95055332 95055165 135 270 360 130 105 70
CRE 15-3 7.5   95055166 135 270 360 180 150 100
CRE 15-4 7.5 95055334 95055167 135 270 360 250 210 140
CRE 15-5 10   95058731 135 270 360 315 255 175
I-QS Hydro MPC E CRE 20
2 CRE 20-2 5 4" ANSI 150# 95055305 95055136 110 220 300 130 105 60
CRE 20-3 7.5 95055306 95055137 110 220 300 195 160 100
CRE 20-4 10   95055138 110 220 300 265 215 125
3 CRE 20-2 5 4" ANSI 150# 95055336 95055170 165 330 450 130 105 60
CRE 20-3 7.5 95055337 95055171 165 330 450 195 160 100
CRE 20-4 10   95055172 165 330 450 265 215 125
I-QS Hydro MPC E CRE 32
2 CRE 32-2-1 7.5 4" ANSI 150# 95058707 95058725 160 300 420 160 125 70
CRE 32-3-2 10   95055141 160 300 420 230 180 100
3 CRE 32-2-1 7.5 6" ANSI 150#   95058732 240 450 630 160 125 70
I-QS Hydro MPC E CRE 45
2 CRE 45-2 15 6" ANSI 150#   95058753 240 440 600 210 185 130
Minimum recommended tank size

DESCRIPTION TANK SIZE  PART #

Diaphragm Tank CR 3, CR5 4.4 Gal. (Non-Code)
Diaphragm Tank CR 10 10.3 Gal. (Non-Code)
Diaphragm Tank CR 15, CR 20 34 Gal. (Non-Code)
Diaphragm Tank CR 32 44 Gal. (Non-Code)
Diaphragm Tank CR 45 86 Gal. (Non-Code)
Diaphragm Tank CR 10 14 Gal. 250 psi ASME
Diaphragm Tank CR 15, CR 20 34 Gal. 250 psi ASME
