Grundfos Hydro Multi-B EZ-Selection Chart

*Blue numbers are the link to Quick Curves and Submittal Sheets.

*Red numbers are the link to the product support information and also indicate products available for the Quick Ship Program.

Quick Curve	System GPM	Head in FT/PSIG	Number of Pumps	Model #-Product Page	HP/Each Pump	Voltage/Phase
91149101	36	90/39	2	91149101	1.5	208-230/1
91149102	36	145/67	2	91149102	1.5	208-230/1
91149103	54	90/39	3	91149103	1.5	208-230/1
91149104	54	145/67	3	91149104	1.5	208-230/1
91149105	52	100/43	2	91149105	1.5	208-230/1
91149106	52	140/60	2	91149106	2	208-230/1
91149107	78	100/43	3	91149107	1.5	208-230/1
91149108	78	140/60	3	91149108	2	208-230/1
91149109	120	55/23	2	91149109	2	208-230/1
91140110	180	56/24	3	91149110	2	208-230/1
91149111	52	140/60	2	91149111	2	208-230/3
91149112	78	140/60	2	91149112	2	208-230/3
91149113	120	120/52	3	91149113	3	208-230/3
91149114	120	180/78	2	91149114	5	208-230/3
91149115	180	120/52	3	91149115	3	208-230/3
91149116	180	180/78	3	91149116	5	208-230/3
91149117	180	70/30	3	91149117	3	208-230/3
91149118	180	140/60	2	91149118	5	208-230/3
91149119	180	210/91	2	91149119	7.5	208-230/3
91149120	270	70/30	3	91149120	3	208-230/3
91149121	270	140/60	3	91149121	5	208-230/3
91149122	270	210/91	3	91149122	7.5	208-230/3
99184377	240	75/32	2	99184377	5	208-230/3
99184379	240	150/65	2	99184379	7.5	208-230/3
99184380	360	75/32	3	99184380	5	208-230/3
99184381	360	150/65	3	99184381	7.5	208-230/3
91149123	52	140/60	2	91149123	2	460/3
91149124	52	180/78	2	91149124	2	460/3
91149125	78	140/60	3	91149125	2	460/3
91149126	78	180/78	3	91149126	3	460/3
91149127	120	120/52	2	91149127	3	460/3
91149128	120	180/78	2	91149128	5	460/3
91149129	180	120/52	3	91149129	3	460/3
91149130	180	180/78	3	91149130	5	460/3
91149131	180	70/30	2	91149131	3	460/3
91149132	180	140/60	2	91149132	5	460/3
91149133	270	210/91	2	91149133	7.5	460/3
91149134	270	70/30	3	91149134	3	460/3
91149135	270	140/60	3	91149135	5	460/3
91149136	270	210/91	3	91149136	7.5	460/3
99184382	240	75/32	2	99184382	5	460/3
99184383	240	150/65	2	91184383	7.5	460/3
99184384	360	75/32	3	99184384	5	460/3
99184385	360	150/65	3	99184385	7.5	460/3
