| Magna 3-Cast Iron Body, Integrated Variable Speed Drive | ||||
| MODEL # | PART # Link | DESCRIPTION | GPM | TDH |
| MAGNA3 32-60 GF | 98126820 | Cast Iron, 115-230V, 1/8 HP, GF15/26 Flanges | 5-40 | 19-5 |
| MAGNA3 32-100 GF | 98126824 | Cast Iron, 115-230V, 1/6 HP, GF15/26 Flanges | ||
| MAGNA3 40-80 | 98126800 | Cast Iron, 115V, 1/3 HP, GF15/26, GF15/40, GF40/43 Flanges | ||
| 98126828 | Cast Iron, 208-230V, 1/3 HP, GF15/26, GF15/40, GF40/43 Flanges | |||
| MAGNA3 40-120 | 98126804 | Cast Iron, 115V, 1/2 HP, GF15/26, GF15/40, GF40/43 Flanges | ||
| 98126832 | Cast Iron, 208-230V, 1/2 HP, GF15/26, GF15/40, GF40/43 Flanges | |||
| MAGNA3 40-180 | 98126808 | Cast Iron, 115V, 3/4 HP, GF15/26, GF15/40, GF40/43 Flanges | ||
| 98126836 | Cast Iron, 208-230V, 3/4 HP, GF15/26, GF15/40, GF40/43 Flanges | |||
| MAGNA3 50-80 | 98126812 | Cast Iron, 115V, 1/3 HP, GF53 Flanges (excluding 3" flange) | ||
| 98126840 | Cast Iron, 208-230V, 1/3 HP, GF53 Flanges (excluding 3" flange) | |||
| MAGNA3 50-150 | 98126816 | Cast Iron, 115V, 3/4 HP, GF53 Flanges (excluding 3" flange) | ||
| 98126844 | Cast Iron, 208-230V, 3/4 HP, GF53 Flanges (excluding 3" flange) | |||
| MAGNA3 65-120 | 98124696 | Cast Iron, 115V, 1 HP, GF65 Flanges | ||
| 98126848 | Cast Iron, 208-230V, 1 HP, GF65 Flanges | |||
| MAGNA3 65-150 | 98126852 | Cast Iron, 208-230V, 1.5 HP, GF65 Flanges | ||
| MAGNA3 80-100 | 98126856 | Cast Iron, 208-230V, 1.5 HP, GF80 Flanges | ||
| MAGNA3 100-120 | 98126860 | Cast Iron, 208-230V, 2 HP, GF100 Flanges | ||
| MAGNA3 65-150 D | 98126863 | Cast Iron, 208-230V, Dual Head 1.5 HP ea, GF65 Flanges | ||
| MAGNA3 80-100 D | 98126864 | Cast Iron, 208-230V, Dual Head 1.5 HP ea., GF80 Flanges | ||
| MAGNA3 100-120 D | 98126865 | Cast Iron, 208-230V, Dual Head 2 HP ea., GF100 Flanges | ||
| Magna 3 Stainless Steel Body, Integrated Variable Speed Drive | ||||
| MODEL # | PART # | DESCRIPTION | GPM | TDH |
| MAGNA3 32-60 GF N | 98126822 | Stainless Steel, 115-230V, 1/8 HP, GF15/26 Flanges | ||
| MAGNA3 32-100 GF N | 98126826 | Stainless Steel, 115-230V, 1/6 HP, GF15/26 Flanges | ||
| MAGNA3 40-80 | 98126802 | Stainless Steel, 115V, 1/3 HP, GF15/26, GF15/40, GF40/43 Flanges | ||
| 98126830 | Stainless Steel, 208-230V, 1/3 HP, GF15/26, GF15/40, GF40/43 Flanges | |||
| MAGNA3 40-120 | 98126806 | Stainless Steel, 115V, 1/2 HP, GF15/26, GF15/40, GF40/43 Flanges | ||
| 98126834 | Stainless Steel, 208-230V, 1/2 HP, GF15/26, GF15/40, GF40/43 Flanges | |||
| MAGNA3 40-180 | 98126810 | Stainless Steel, 115V, 3/4 HP, GF15/26, GF15/40, GF40/43 Flanges | ||
| 98126838 | Stainless Steel, 208-230V, 3/4 HP, GF15/26, GF15/40, GF40/43 Flanges | |||
| MAGNA3 50-80 | 98126814 | Stainless Steel, 115V, 1/3 HP, GF53 Flanges (excluding 3" flange) | ||
| 98126842 | Stainless Steel, 208-230V, 1/3 HP, GF53 Flanges (excluding 3" flg) | |||
| MAGNA3 50-150 | 98126818 | Stainless Steel, 115V, 3/4 HP, GF53 Flanges (excluding 3" flange) | ||
| 98126846 | Stainless Steel, 208-230V, 3/4 HP, GF53 Flanges (excluding 3" flg) | |||
| MAGNA3 65-120 | 98124702 | Stainless Steel, 115V, 1 HP, GF65 Flanges | ||
| 98126850 | Stainless Steel, 208-230V, 1 HP, GF65 Flanges | |||
| MAGNA3 65-150 | 98126854 | Stainless Steel, 208-230V, 1.5 HP, GF65 Flanges | ||
| MAGNA3 80-100 | 98126858 | Stainless Steel, 208-230V, 1.5 HP, GF80 Flanges | ||
| MAGNA3 100-120 | 98126862 | Stainless Steel, 208-230V, 2 HP, GF100 Flanges | ||
| Magna 1 Series Cast Iron Pump with Integral VFD Drive |
||||
| MAGNA1 32-60 | 98126819 | Cast Iron, 115-230V, 1/8 HP, GF15/26 Flanges | ||
| MAGNA1 32-100 | 98126823 | Cast Iron, 115-230V, 1/6 HP, GF15/26 Flanges | ||
| MAGNA1 40-80 | 98126799 | Cast Iron, 115V, 1/3 HP, GF15/26, GF15/40, GF40/43 Flanges | ||
| 98126827 | Cast Iron, 208-230V, 1/3 HP, GF15/26, GF15/40, GF40/43 Flanges | |||
| MAGNA1 40-120 | 98126803 | Cast Iron, 115V, 1/2 HP, GF15/26, GF15/40, GF40/43 Flanges | ||
| 98126831 | Cast Iron, 208-230V, 1/2 HP, GF15/26, GF15/40, GF40/43 Flanges | |||
| MAGNA1 40-180 | 98126807 | Cast Iron, 115V, 3/4 HP, GF15/26, GF15/40, GF40/43 Flanges | ||
| 98126835 | Cast Iron, 208-230V, 3/4 HP, GF15/26, GF15/40, GF40/43 Flanges | |||
| MAGNA1 50-80 | 98126811 | Cast Iron, 115V, 1/3 HP, GF53 Flanges (excluding 3" flange) | ||
| 98126839 | Cast Iron, 208-230V, 1/3 HP, GF53 Flanges (excluding 3" flange) | |||
| MAGNA1 50-150 | 98126815 | Cast Iron, 115V, 3/4 HP, GF53 Flanges (excluding 3" flange) | ||
| 98126843 | Cast Iron, 208-230V, 3/4 HP, GF53 Flanges (excluding 3" flange) | |||
| MAGNA1 65-120 | 98124695 | Cast Iron, 115V, 1 HP, GF65 Flanges | ||
| 98126847 | Cast Iron, 208-230V, 1 HP, GF65 Flanges | |||
| MAGNA1 65-150 | 98126851 | Cast Iron, 208-230V, 1.5 HP, GF65 Flanges | ||
| MAGNA1 80-100 | 98126855 | Cast Iron, 208-230V, 1.5 HP, GF80 Flanges | ||
| MAGNA1 100-120 | 98126859 | Cast Iron, 208-230V, 2 HP, GF100 Flanges | ||
| Magna 1 Series Stainless Steel Pump with Integral VFD Drive | ||||
| MAGNA1 32-60 | 98126821 | Stainless Steel, 115-230V, 1/8 HP, GF15/26 Flanges | ||
| MAGNA1 32-100 | 98126825 | Stainless Steel, 115-230V, 1/6 HP, GF15/26 Flanges | ||
| MAGNA1 40-80 | 98126801 | Stainless Steel, 115V, 1/3 HP, GF15/26, GF15/40, GF40/43 Flanges | ||
| 98126829 | Stainless Steel, 208-230V, 1/3 HP, GF15/26, GF15/40, GF40/43 Flanges | |||
| MAGNA1 40-120 | 98126805 | Stainless Steel, 115V, 1/2 HP, GF15/26, GF15/40, GF40/43 Flanges | ||
| 98126833 | Stainless Steel, 208-230V, 1/2 HP, GF15/26, GF15/40, GF40/43 Flanges | |||
| MAGNA1 40-180 | 98126809 | Stainless Steel, 115V, 3/4 HP, GF15/26, GF15/40, GF40/43 Flanges | ||
| 98126837 | Stainless Steel, 208-230V, 3/4 HP, GF15/26, GF15/40, GF40/43 Flanges | |||
| MAGNA1 50-80 | 98126813 | Stainless Steel, 115V, 1/3 HP, GF53 Flanges (excluding 3" flange) | ||
| 98126841 | Stainless Steel, 208-230V, 1/3 HP, GF53 Flanges (excluding 3" flange) | |||
| MAGNA1 50-150 | 98126817 | Stainless Steel, 115V, 3/4 HP, GF53 Flanges (excluding 3" flange) | ||
| 98126845 | Stainless Steel, 208-230V, 3/4 HP, GF53 Flanges (excluding 3" flange) | |||
| MAGNA1 65-120 | 98124701 | Stainless Steel, 115V, 1 HP, GF65 Flanges | ||
| 98126849 | Stainless Steel, 208-230V, 1 HP, GF65 Flanges | |||
| MAGNA1 65-150 | 98126853 | Stainless Steel, 208-230V, 1.5 HP, GF65 Flanges | ||
| MAGNA1 80-100 | 98126857 | Stainless Steel, 208-230V, 1.5 HP, GF80 Flanges | ||
| MAGNA1 100-120 | 98126861 | Stainless Steel, 208-230V, 2 HP, GF100 Flanges | ||
